Swaged Louvers Contribute to Energy Conservation & Emission Reduction

Swaged louvers are a kind of fixed louvers made of aluminum alloy and act as standard and trafficable sunscreen louvers. Its metal properties allow it to absorb part of the heat energy and lower the temperature. In this way, it can reduce the use of indoor air conditioning, thereby achieving the purpose of energy conservation and emission reduction. Meanwhile, its louver shape keeps air circulating freely, thus achieving ventilation.

Swaged louvers, made of aluminum alloy, are light in weight and inexpensive, and are widely used as sunshades, window louvers, external awnings at building facades, rooftops and windows of parking lots, offices, apartments, commercial buildings and other places.

Features

● Temperature reduction. Made of aluminum alloy, it can absorb heat energy and lower the temperature, therefore, it can be used in exterior walls of buildings.

● Shading & ventilation. Its louver shape enables it block sunlight while allowing the air circulate freely.

● Corrosion resistance. Made of superior aluminum plate, together with anodized or power coated surfaces makes the swaged louvers have excellent resistance to corrosion and rust, and enjoy an extended service life.


Category


Aluminum sunscreen louvers

It consists of aluminum louver blades and square rob cross bar. Reinforcing ribs on blades s beautiful and strengthen the blades at the same time.

It is widely used in offices, commercial buildings, parking lots and other places and function as door louvers, window louvers, ventilation louvers, facade sunshades or decoration grilles.

For specification of aluminum sunscreen louvers, please refer to Table 1 listed below.


Aluminum trafficable louvers

Similarly, aluminum trafficable louvers consist of louver blades and square cross bars. The difference between sunscreen louvers and trafficable louvers lays in flat bars added between every two blades to make the trafficable louvers stronger to bear more weight. It allows people to walk or stand on and guarantees the safety of pedestrians.

It is widely used in offices, commercial buildings, parking lots and other places and serve as door louvers, window louvers, ventilation louvers and facade sunshades. Besides, addtional bearing bar are added can permit people stepping to clean and repair building facades and windows.

For specification of aluminum trafficable louvers, please refer to Table 2 listed below.


Specification



Table1: Specification of Aluminum Swaged Sunscreen Louvers

ModelBlade Drop W (mm)Toe Depth D (mm)Blade Angle A (°)Blade Pitch P (mm)Blade Thickness T (mm)
EZSL6032100606032100°603
EZSL4520135304520135°303
EZSL4520135604520135°603
EZSL6020135306020135°303
EZSL6020135606020135°603
EZSL6032135306032135°303
EZSL6032135606032135°603
EZSL6040135306040135°303
EZSL6040135606040135°603
EZSL8020135308020135°303
EZSL8020135608020135°603
EZSL8032135308032135°303
EZSL8032135608032135°603
EZSL6032160306032160°303
EZSL6032160606032160°603
Note:Other specifications are available upon request.



Table2: Specification of Aluminum Swaged Trafficable Louvers
ModelBlade Drop W (mm)Toe Depth D (mm)Blade Angle A (°)Blade Pitch P (mm)Blade Thickness T (mm)
ESTL6020135606020135°603
ESTL6032135606032135°603
ESTL6040135606040135°603
ESTL8020135608020135°603
ESTL8032135608032135°603
Note:Other specifications are available upon request.


Applications

Swaged louvers are widely used in parking lots, offices, apartments, commercial buildings, etc.


● In parking lots, it can be used at the facades, entrances and exits for shading and ventilation.

● In offices, it can be used as window louvers or ventilation louvers.

● In apartments, it can be used as sunshades of doors and windows or as ventilation louvers on the rooftops.

● It can be used as awnings of commercial buildings or as facades of buildings, etc.



For parking lots ventilation louvers



For offices window louvers



For apartments sunshades



For building facade sunshades


For commercial buildings decoration grilles


For building external awnings
